Key Features
High-Precision Analysis
Rapidly identifies and quantifies dissolved fault gases in transformer insulating oil with high accuracy.
Flexible Detector Configuration
Supports FID, TCD, ECD, and FPD detectors to meet diverse testing requirements.
High-Level Automation
Supports automatic sample injection and optional auto sampler for improved efficiency and repeatability.
Precise Temperature Control
Ensures excellent chromatographic separation and stable, reliable analytical performance.
Technical Specifications & Operating Conditions
|
Model |
HYQS |
|
Operation & Display |
192 × 64 dot‑matrix LCD |
|
Temperature‑controlled Zones |
6 channels |
|
Temperature Control Range |
Ambient temperature +5 ℃ ~ 400 ℃ Temperature increment: 1 ℃, Accuracy: ±0.1 ℃ |
|
Programmed Temperature‑ramp Stages |
16 stages |
|
Program‑ramp Rate |
0.1 ~ 40 ℃/min |
|
Gas Path Control |
Optional: mechanical valve control / electronic pressure & flow control |
|
External Events |
4 channels |
|
Injector Types |
Optional: packed‑column, capillary column, 6‑port valve gas injection, automatic headspace injection, etc. |
|
Number of Detectors |
4 units; FID, TCD, ECD, FPD (optional configuration) |
|
Initiation of Sample Injection |
Optional: manual / automatic |
|
Communication Interface |
Ethernet: IEEE802.3 |
