Key Features：
Standard Compliance
It conforms to GB510-83 and GB/T 3535-83 standards, applicable for oil testing in power, petroleum and chemical industries, and can replace imported similar instruments.
Advanced Hardware Design
Equipped with high-performance microprocessor and semiconductor refrigeration technology. It adopts high-definition color touch screen with Chinese display for easy human-machine interaction.
Intelligent Diagnosis Function
Built-in self-diagnosis function facilitates equipment troubleshooting.
Superior Testing Performance
Fast sample analysis with accurate test data, excellent repeatability and stable & reliable operation.
Technical Specifications & Operating Conditions
|
Model |
HYNQ-3 |
|
Temperature Sensor |
Platinum Resistance |
|
Temperature Accuracy |
±1℃ |
|
Temperature Resolution |
0.1℃ |
|
Measuring Range |
Ambient Temperature to -70℃ |
|
Display |
7-inch Color Touch Display |
|
Data Storage |
500 sets of test data |
|
Clock Function |
Data retention after power failure |
|
Sample Volume |
20ml per test |
|
Cooling Water Requirement |
Pressure: 49 kPa ~ 490 kPa; Flow Rate: 1.5 L/min |
|
Power Supply |
AC 220 V±22 V |
|
Power Frequency |
50 Hz±2.5 Hz |
|
Power Consumption |
≤250 VA |
|
Ambient Temperature |
10~35 ℃ |
|
Relative Humidity (RH) |
≤85% |
|
Net Weight |
Approx. 25 kg |
